DI-9760 DI-97120 DI-97240 DI-97350 DI-97500 IP Network Amplifier
DI-97500 series is one IP based network amplifier, which integrate 100V mixer amplifier, media player and IP audio decoder together. The IP network amplifier could be remotedly controlled by software. The IP network audio system will be used for long distance transmission to save much cable layout cost.
IP Network Amplifier
DI-9760 DI-97120 DI-97240 DI-97350 DI-97500
Description:
The IP Network Amplifier combines the IP audio decoder/IP streaming and 100V/8 Ohm amplifier together. The IP network amplifier is of 19” rack mount design, it is built-in amplifier rated output at 60W, 120W, 240W, 350W to 500W. The IP network technology also allow this IP network amplifier could be installed anywhere even near to the speaker to save cable wiring from control room to each zone. The advantages of the network audio system are: long distance transmission, multiple channel audio matrix, simultaneous group programs & non-dedicated network wiring.
Feature:
IP network mixer amplifier with audio decoder.
Simple configuration by system server, paging microphone & IP network amplifier to set up IP audio system.
Huge system capacity of 6,000 zones paging and multiple BGM system.
IP based public address system over LAN/WAN or Internet.
Minimum cable connection by using existing network framework.
Non-dedicated network audio system solution.
Economy network PA system for multiple room and multiple program applications.
Ideal for school, office, restaurant and fitness center IP PA sound system.
IP network decoder built-in 100V/8 Ohm Amplifier.
Rated power output of 60W, 120W, 240W & 350W.
Mic1-3 inputs and line1-2 inputs and one line output.
One control input and two control outputs
Enable to broadcast Mp3 program or pre-recorded voice message from PC server to IP amplifier.
Remote volume control and program control from server room.
Timely broadcast ring bell or pre-recorded message to pre-set zones.
IP remote paging microphone enables to talk to each speaker zone or amplifier over network.
Specification:
Model | DI-9760 | DI-97120 | DI-97240 | DI-97350 | DI-97500 |
Description | IP Network Amplifier | ||||
Power Output | 60W | 120W | 240W | 350W | 500W |
Protocol Support | TCP/IP, UDP, IGMP (group broadcasting) | ||||
Transmit Speed | 10/100Mbps | ||||
Audio Format | 16 digit stereo CD tone | ||||
Frequency Response | 20Hz~16KHz | ||||
THD | ≤0.3% | ||||
S/N Ratio | ≥85dB | ||||
Connector | One RJ45 port, Mic1-3 inputs and line 1-2 input and one line output, One control input and two control outputs | ||||
Speaker Output | 100V/70V & 4-16 Ohm | ||||
Working Temp | -5℃ to +40℃ | ||||
Humidity | 10% ~ 90% | ||||
Power Consumption | 95W | 175W | 350W | 485W | 650W |
Power Supply | AC220V, 50-60Hz | ||||
Dimensions | 484x366x88mm | ||||
Weight | 10.5kg | 11.5kg | 13.8kg | 14.5kg | 15.5 |
