WS-101 Chairman Discussion Unit WS-102 Delegate Discussion Unit

2025-12-09 17:37:12

Click：

“ The chairman unit has the ability to forcibly shut down the delegate units of delegates who are currently speaking; it can be freely activated regardless of the number of speakers or speaking mode, and is not limited by installation location; ”

Features:

Novel and stylish appearance, ergonomic design;
Support discussion functions;
Uses a dedicated 8-core high-density aviation connector, comes with a 2-meter connecting cable, and a 'T-type' connection mode to ensure reliable connection;
Cardioid condenser microphone with a built-in speaking indicator light (red when speaking), and is detachable during breaks;
The chairman unit is not limited by the number of speakers, and its connection location is unrestricted;
Microphone gooseneck length: 450mm (standard configuration);
The unit is a passive device, powered by the system host, with an input voltage of DC24V;
The chairman unit has the ability to forcibly shut down the delegate units of delegates who are currently speaking; it can be freely activated regardless of the number of speakers or speaking mode, and is not limited by installation location;

Specification:

Model	WS-101	WS-102
Description	Chairman Unit	Delegate Unit
System Capacity	256pcs mic connection maximum
Connection Way	Hand in hand by 8 PIN cable
Power Supply	24V DC by controller WS-100MC
Power Consumption	2W
Voice Pickup Distance	20-50cm
THD	<0.05%
S/N Ratio	>75dB
Frequency Response	45Hz-18 KHz
Crosstalk Attenuation	>80dB
Indicator	Red round ring indicator light on when microphone on
Gooseneck Length	450 mm
Connector	8 PIN connector
Finish	Metal in black
Dimension	135 ×45 mm
Weight	1kg
